355nm UV laser with cold marki…
| Specification | UV Laser Marking Machine This model | DLM-UA-3 UV Flying High-Speed Laser Marker | DLM-UA-5 UV Flying High-Speed Laser Marker |
|---|---|---|---|
| Laser Source | UV Solid-State 355nm | — | — |
| Power | 3W / 5W / 10W / 20W | — | — |
| Marking Area | 110×110mm / 175×175mm | — | — |
| Marking Speed | ≤6000mm/s | ≤7000mm/s | ≤7000mm/s |
| Cooling | Air-Cooled / Water-Cooled | — | — |
| dlm-ua-03 | — | DLM-UA-05 | DLM-UA-05 |
| Brand | — | JCZ - LV7 | JCZ - LV7 |
| 3w | — | 5W | 5W |
| 20~100khz | — | 40~300kHz | 40~300kHz |
| Pulse Width Range | — | 15~25ns@30kHz (Differences In Brand) | 15~25ns@30kHz (Differences In Brand) |
| Q Pulse Width | — | 1~33Us | 1~33Us |
| Dual Red Light | — | Manual (Optional Dual Red Light Focusing) | Manual (Optional Dual Red Light Focusing) |
| Marking Range | — | 110*110mm (Optional 150*150mm / 175*175mm / 220*220mm / 300*300mm) | 110*110mm (Optional 150*150mm / 175*175mm / 220*220mm / 300*300mm) |
| Focal Length Height | — | F=163mm | F=163mm |
| Min Line Width | — | 0.06mm @ F=163mm (Differences In Materials) | 0.06mm @ F=163mm (Differences In Materials) |
| Min Character | — | 0.2mm @ F=163mm | 0.2mm @ F=163mm |
| Repeatability Accuracy | — | 0.01mm | 0.01mm |
| Software | — | Ezcad2,Compatible with LightBurn | Ezcad2,Compatible with LightBurn |
| Support System | — | Windows | Windows |
| Support File Formats | — | Jpg | Jpeg | Bmp | Gif | Png | Ai | Plt | Dxf | Svg | Jpg | Jpeg | Bmp | Gif | Png | Ai | Plt | Dxf | Svg |
| Software Language | — | Chinese | English | French | Russian| German | Italian |Korean | Japanese etc. | Chinese | English | French | Russian| German | Italian |Korean | Japanese etc. |
| Lifting Method | — | Manual Lifting (Optional Electric Lifting) | Manual Lifting (Optional Electric Lifting) |
| Computer | — | Industrial Control Computer (Intel I5+8G+128G;19'LCD) | Industrial Control Computer (Intel I5+8G+128G;19'LCD) |
| Air Cooling / Water Cooling | — | Water cooling | Water cooling |
| Power Supply | — | 110~220V 50Hz~60Hz | 110~220V 50Hz~60Hz |
CE · ISO 9001 · FDA-compliant manufacturing
Full technical support & global service network
Best quote with free sample test & fast delivery
355nm UV laser with cold marking technology. Zero thermal damage on plastics, glass, and sensitive materials. Ideal for medical and electronics.
| Laser Source | UV Solid-State 355nm |
|---|---|
| Power | 3W / 5W / 10W / 20W |
| Marking Area | 110×110mm / 175×175mm |
| Marking Speed | ≤6000mm/s |
| Cooling | Air-Cooled / Water-Cooled |
Watch the marking demo on various materials
Want to see how it performs on your materials? Request a free sample test.
This machine can permanently mark most metals including steel, stainless steel, iron, aluminum, copper, brass, titanium, gold, silver, and hard alloys. It also works on ABS, PVC, PC, nylon, and other hard plastics.
The machine comes with EZCAD software (Windows) included at no extra cost. It is also compatible with LightBurn, a popular third-party laser control software.
Air-cooled models require no external water chiller — just plug into a standard power outlet. Cabinet models have built-in cooling fans.
Yes, you can upgrade the marking area by replacing the F-theta lens. We sell F-theta lenses separately and can guide you through installation.
Supported formats include PLT, DXF, AI, SVG, JPG, GIF, BMP, PNG, and more. Both vector and raster files are supported.
